TTi Adjustable Ratchet

Part number: 13830
EAN Bar Code: 5060207566018
NATO number: 5120-99-344-4194
Accuracy: ±3%
Operates between: 4.00 - 20.00 N·m
35.00 - 180.00 lbf·in (1.00 Increment)

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 230 mm
- Square Size: 1/4"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
- Scale Increments (lbf·in): 10
Description
Dimensions & Weights
Tool Weight (kg): 0.44

Packed Weight* (kg): 0.52
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13830
TTi20 1/4", 4 - 20 N·m, 35 - 180 lbf·in

Part number: 13831
EAN Bar Code: 5060207566025
NATO number: 5120-99-313-7261
Accuracy: ±3%
Operates between: 4.00 - 20.00 N·m (0.05 Increment)
35.00 - 180.00 lbf·in (0.50 Increment)

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 230 mm
- Square Size: 3/8"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
- Scale Increments (lbf·in): 10
Description
Dimensions & Weights
Tool Weight (kg): 0.44

Packed Weight* (kg): 0.52
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13831
TTi20 3/8", 4 - 20 N·m, 35 - 180 lbf·in

Part number: 13841
EAN Bar Code: 5060207566117
NATO number: 5120-99-154-0947
Accuracy: ±3%
Operates between: 10.00 - 50.00 N·m
8.00 - 35.00 lbf·ft

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 329 mm
- Square Size: 3/8"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
- Scale Increments (lbf·ft): 1
Description
Dimensions & Weights
Tool Weight (kg): 0.61

Packed Weight* (kg): 0.69
Packed Width* (W) (mm): 354.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13841
TTi50 3/8", 10 - 50 N·m, 8 - 35 lbf·ft

Part number: 13842
EAN Bar Code: 5060207566124
NATO number: 5120-99-154-0949
Accuracy: ±3%
Operates between: 10.00 - 50.00 N·m
8.00 - 35.00 lbf·ft

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 329 mm
- Square Size: 1/2"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
- Scale Increments (lbf·ft): 1
Description
Dimensions & Weights
Tool Weight (kg): 0.62

Packed Weight* (kg): 0.70
Packed Width* (W) (mm): 354.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13842
TTi50 1/2", 10 - 50 N·m, 8 - 35 lbf·ft

Part number: 13832
EAN Bar Code: 5060207566032
NATO number:
Accuracy: ±3%
Operates between: 4.00 - 20.00 N·m

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 230 mm
- Square Size: 1/4"
- Ratchet Diameter: 30
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
Description
Dimensions & Weights
Tool Weight (kg): 0.44

Packed Weight* (kg): 0.52
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13832
TTi20 N·m 1/4", 4 - 20 N·m only

Part number: 13833
EAN Bar Code: 5060207566049
NATO number:
Accuracy: ±3%
Operates between: 4.00 - 20.00 N·m

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 230 mm
- Square Size: 3/8"
- Ratchet Diameter: 30
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
Description
Dimensions & Weights
Tool Weight (kg): 0.44

Packed Weight* (kg): 0.52
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13833
TTi20 N·m 3/8", 4 - 20 N·m only

Part number: 13843
EAN Bar Code: 5060207566131
NATO number:
Accuracy: ±3%
Operates between: 10.00 - 50.00 N·m

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 329 mm
- Square Size: 3/8"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
Description
Dimensions & Weights
Tool Weight (kg): 0.61

Packed Weight* (kg): 0.69
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated

Part No. 13843
TTi50 N·m 3/8", 10 - 50 N·m only

Part number: 13844
EAN Bar Code: 5060207566148
NATO number:
Accuracy: ±3%
Operates between: 10.00 - 50.00 N·m

Features
- Micrometer Scale for simple and error free setting. (On dual scale wrenches, the micrometer increment applies to the N·m scale.)
- Quick and Light Adjustment: adjustment over the entire scale can quickly be achieved and with minimal effort in approximately ten complete turns (exact number varies by model).
- Comfortable, Durable Handle: the handle is constructed using two materials; a base material for strength overlaid with a soft feel grip for comfort and slip resistance.
- The handle material and lens resist chemicals in common usage in the automotive, aviation and industrial environments.
- Supplied with a Declaration of Conformance, which meets the requirements of ISO 6789-1:2017
Technical Specifications
- Length: 329 mm
- Square Size: 1/2"
- Ratchet Diameter: 30 mm
- Engagements per Revolution: 72
- Scale Increments (N·m): 0.1
Description
Dimensions & Weights
Tool Weight (kg): 0.62

Packed Weight* (kg): 0.70
Packed Width* (W) (mm): 258.00

Packed Height* (H) (mm): 50.00

Packed Depth* (D) (mm): 50.00
* Estimated
