This product is now obsolete, for details of the new, re-engineered model please click here
HandTorque models HT30 and 60 have all the features of the standard series, but have a higher torque output for a given gearbox diameter.
Anti Wind-Up Product Video
- Part number:
18004
- EAN Bar Code:
5060207567848
- NATO number:
-
- Accuracy:
±4%
- Operates between:
220.00 -
2200.00
lbf·ft
300.00 -
3000.00
N·m
30.00 -
300.00
kgf·m
Compare Products
Please select further products to compare.
- Features
-
Reduced diameter allows better access, particularly on pipe flanges.
-
Reaction taken from high strength spline.
-
Reaction foot can slide on the spline to allow for sockets of various lengths.
-
Anti Wind-Up Ratchet available on all models (except 5:1 ratios), allowing safer and more practical operation.
-
HT45 has integral angle protractor for easy torque and angle tightening.
- Technical Specifications
-
Tool Weight: 7 Kg
-
Multiplication Ratio: 15:1
-
Output Square: 1"
-
Input Square: 1/2"
-
Velocity Ratio: 17.075:1
-
Max Input Speed: 72 revs/min
-
Plate Weight: 2 Kg
