These loaders allow torque wrenches to be calibrated or tested in accordance with ISO 6789:2003, BS EN 26789:2003. Their function is to take full advantage of the accuracy of Norbar's torque measuring systems by reducing operator induced variations in the calibration process.
- Part number:
20505
- EAN Bar Code:
5060922234032
- NATO number:
-
- Accuracy:
-
- Operates between:
10.00 -
3000.00
N·m
10.00 -
2200.00
lbf·ft
Compare Products
Please select further products to compare.
- Features
-
The design allows for easy interchange of transducers using the Norbar Static Transducer system
-
Floating reaction point minimises side loads on wrench.
-
Optional Small Reaction Plate (Part Code 20606) allows torque wrenches down to 125mm in length to be tested.
-
The high ratio, 1250:1 gearbox allows high torques to be applied, whilst ensuring that the operator does not exceed the rate of increase of torque specified in the standards.
-
Reaction extension bar allows wrenches up to 2250 mm to be tested. This can be removed to save space.
-
Includes a selection of adapters to enable torque wrenches to be calibrated with an appropriate transducer
- Technical Specifications
-
Length: 2521 mm
-
Weight: 55 Kg
-
Height: 535 mm
-
Depth: 446 mm
-
Minimum Torque Wrench Length: 220 mm (8.6")
-
Maximum Torque Wrench Length: 2250 mm (87")
